Barco RLM-W14 Service Manual

19 of 149
Barco RLM W14 Operation Commands
Command
Item
Operation
Commands
Values
Notes
2-20
color.space2
= ?
0 = Auto
1 = YUV HD
2 = YUV STD
3 = RGB-PC (0-255)
4 = RGB-Video (16-235)
Note2
3-1
zoom
= ?
0 = Off
1 = Crop
2 = Zoom
Note2; Note6
3-2
pip.sel
= ?
1 = HDMI
2 = HDBaseT
3 = RGB D-15
4 = YUV 1
5 = RGBHV/YUV2
6 = Reserve
7 = Reserve
8 = Reserve
9 = SDI/HDSDI/3G
Note1;
Note9;
Please refer to
appendix 1 for
the valid
main/pip source
selection
3-3
pip.pos
= ?
0 = Top left
1 = Top right
2 = Bottom left
3 = Bottom right
4 = Split L-R
Note1;
Note10
3-4
pip
= ?
0 = Off
1 = On
Note1
4-1
lamp.mode
= ?
0 = Economy
1 = Standard
2 = Dimming
Note2
4-2
lamps
= ?
0 = Single
1 = Dual
Note1;
Note11
4-3
altitude
= ?
0 = Off
1 = On
Note1
4-4
lamp.pwr
= ?
0-35 ( 78.3 % ~100 % )
Note2
4-5
lamp1.stat
?
0 = Off
1 = On
Note1
