32 of 149
Note13: Only MCU version number will be read back in standby mode.
Note14: Not applicable when the internal pattern is displayed.
Note15: The summation of the absolute value of h.keystone and v.keystone should not be greater than 350.
Note16: Per Geo Semi’s specification, the minimum blend size is 200, values in the range 1 ~ 199 are not
allowed.
Note17: Per Geo Semi’s specification, black level (position) adjustment will only work with an active white level
setting on the corresponding side.
Note18: When scen.red, scen.green, scen.blue values are not equal, the command will get back“NA”in
reading.
Note19: Only available when “STEREO DVI” source is active.
Note20: Available for all acvtive source inputs including “STEREO DVI”, however the performance not
guaranteed under “STEREO DVI” input.
Note21: PLGC adjustment memory scheme is per dark-time, lamp-mode, refresh-rate as the following table.
PLGC adjustment should be made for each of the conditions that will the used in the 3D applications. The
adjusted PLGC values will be memorized and stored based on the current dark-time, lamp-mode setting, and the
refresh-rate of the active signal.
Note22: All the PLGC adjustment memory in the above matrix will be reset to default.
