R5911443 /02 UDM130
Image 10-32: Reset menu
2. Navigate to the checkbox next to the settings that need to be reset and press OK.
Multiple selections are possible.
3. Select RESET and press OK to reset all selected settings.
10.12 Lens Calibration
Lens calibration is a time consuming operation.
How to calibrate
1. In the main menu, System Settings → Maintenance → Lens Calibration.
Image 10-33: Maintenance menu, Lens Calibration
The Lens Calibration menu is displayed.
Image 10-34: Lens Calibration menu
2. In the Lens Calibration menu, select the desired calibration action and click OK.
You can select one of the following functions:
• Horizontal shift
• Vertical shift
GUI – System Settings
