R5911443 /02 UDM150
Max. pixel clock 600 MHz
Software tools Projector Toolset + Android** app + iOS** app
Control XLR wired + IR, RS232, Wifi**, GSM **
Network connection 10/100 base-T, RJ-45 connection, Wifi**
Power requirements 120-160 V (reduced power) 18.5A / 200-240V (+/-10%), 13.5A, 50-60Hz
Max. power consumption TBD
Noise level (typical at 25°C/
77°F)
TBD
Operational ambient
temperature
0-40°C / 32°-104°F***
Operational humidity 0-80% (non condens)
Dissipation BTU TBD
Dimensions (WxLxH) 725 x 540 x 339 mm / 28.54 x 21.25 x 13.36 inches
Shipping Dimensions incl. pallet
(WxLxH) 850 x 665 x 613 mm / 33.46 x 26.18 x 24.13 inches
Weight 48 kg (105 lbs) / shipping weight from factory: 61 kg (134 lbs)
Standard accessories Power cord, wireless / XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1, complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
Notes *Brightness levels +/- 10%
** Wifi and GSM options are not available in all countries. Check with your
Barco representative for more info.
***at higher altitude light output might be dimmed
A.5 Specifications SDI inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
HD-SDI follows the SMPTE 292M standard.
3G SDI follows the SMPTE 425M standard Level A.
12G-SDI
3
follows the SMPTE ST-2082-1 and ST-2082-10 standards.
SDI specifications
Specification
Value
Color space YCbCr
Color depth 10 bpc
Chroma sampling 4:2:2
Audio not supported
Specifications
3: Quad Combo Input Mk II only.
