R5911443 /02 UDM 145
24hz to 120hz 4K/4KUHD (4096 x 2160 / 3860 x 2400) to 240hz WQXGA
(2560 x 1600)
Max. pixel clock 600 Mhz
Software tools Projector Toolset + Android** app + iOS** app
Control XLR wired + IR, RS232, Wifi**, GSM**
Network connection 10/100 base-T, RJ-45 connection, Wifi**
Power requirements 120-160 V (reduced power)18.5A / 200-240V (+/- 10%), 13.5A, 50-60Hz
Max. power consumption 1800W nom/ 2400w max@230 volts ECO STBY<2W
1560W nom/ 1950w max @ 120 voltsECO STBY<2W
Noise level (typical at 25°C/
77°F)
49 dB(A) (TBD)
Operational ambient
temperature
0-40°C / 32°-104°F ***
Operational humidity 0-80% (non condens)
Dissipation BTU Max. 6,900 BTU/h
Dimensions (WxLxH) 725 x 540x 339 mm / 28.54 x 21.26 x 13.3'
Shipping Dimensions incl. pallet
(WxLxH) 850 x 665 x 613 mm / 33.46 x 26.18 x 24.13 inches
Weight 48 kg (105lbs) / shipping weight from factory: 61 kg (134.5 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1, complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
*Note *Brightness levels +/- 10%
** Wifi and GSM options are not available in all countries. Check with your
Barco representative for more info.
***at higher altitude light output might be dimmed
A.2 Specifications for UDM 4K15
Specifications
Projector type 4K UHD 3-chip DLP digital projector
Technology 0.98" DMDTM x3
Resolution 3,840 x 2,400 (4K UHD) / 2,560 x 1,600 (native) / 5,120 x 3,200
(processing)
Brightness 14,500 (4K UHD) center lumens / 14,000 (4K UHD) ansi lumens*
15,000 ISO lumens*
Contrast ratio 2200:1
Brightness uniformity 95%
Aspect ratio 16:10
