Barco UDM Series User Manual

R5911443 /02 UDM 151
Specification
Value
For future release
• 3D support
• Interlaced support
• Segmented frame support
Video timings
progressive
4
Type Port type Format
HD-SDI Single link
Quad link
• Up to 1920 x 1080 @24 Hz
• Up to 1920 x 1080 @25 Hz
• Up to 1920 x 1080 @30 Hz
• Up to 1280 x 720 @50 Hz
• Up to 1280 x 720 @60 Hz
3G-SDI Level A
5
Single link
Quad link
Up to 2048 x 1080 @50 Hz
Up to 2048 x 1080 @60 Hz
3G-SDI
“BarcoLink”
Single link
Quad link
1920 x 1200 @50 Hz, @59.94 Hz and
@60 Hz
12G-SDI (Channel
A only)
Single link 3840 x 2160 @50 Hz and @60 Hz
4096 x 2160 @50 Hz and @60 Hz
12G-SDI
“BarcoLink 4k”
(Channel A only)
Single link 3840 x 2400 @50 Hz, @59.94 Hz and
@60 Hz.
A.6 Specifications HDMI inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
HDMI specifications
Specification
Value
Pixel rate 25 – 600 MHz pixel clock
HDCP support
• HDCP 1.x
• HDCP 2.2
• RGB 4:4:4
Color space
• YCbCr 4:2:0
• YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth
• 24 bpp
• 30 bpp
• 36 bpp
3D support
• Field sequential 3D (Active 3D)
- Frame-packed
- Top Bottom progressive
- Side-by-side progressive
• Passive 3D not supported.
For future release
• Interlaced support
Audio Not supported
Specifications
4: For the full list of video timings, see Appendix user guide
5: Quad Combo Input Mk I only.
