Barco UDM Series - Specifications HDBaseT Inputs

R5911443 /02 UDM152
Specification
Value
Video timings
4
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @25 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 4096 x 2160 @50 Hz
• Up to 4096 x 2160 @60 Hz
Native video timings
• UDM-W: 1920 x 1200 @60 Hz
• UDM-4K: 3840 x 2400 @60 Hz
A.7 Specifications HDBaseT inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
HDBase T specifications
Specification Value
Pixel rate 25 – 297 MHz pixel clock
Color space
• YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth
• 24 bpp
• 30 bpp
• 36 bpp
HDCP support HDCP 1.x supported on HDBaseT Input 1
Network support Yes, on HDBaseT Input 1
For future release
• 3D support
• Interlaced support
Audio not supported
Video timings
progressive
4
Layout mode Supported formats
Standard layout (1x1
layout)
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @25 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 2560 x 1600 @50 Hz
• Up to 2560 x 1600 @60 Hz
2 Column mode (2x1
layout)
• 1920 x 2160 @50 Hz
• 1920 x 2160 @60 Hz
• 2048 x 2160 @50 Hz
• 2048 x 2400 @60 Hz
Native video timings
• UDM-W: 1920 x 1200 @60 Hz
• UDM-4K: 3840 x 2160 @60 Hz
Specifications
