8.1 Configuring the lens, optical zoom-focus
What can be done?
Once a lens has been installed in the projector, you can fine-tune the projected image.
Zoom - Focus
1. In the main menu, select Installation → Lens → Zoom focus.
Image 8-1: Lens menu, Focus & Zoom
2. Use the ▲ or ▼ key to zoom the lens in or out.
Use the ◄ or ► key to focus the lens to far or near.
Image 8-2: Zoom and focus adjustment
