R5906112 /09 UDX series 177
10.13 Lens Calibration
Lens calibration is a time consuming operation.
How to calibrate
1. In the main menu, System Settings → Maintenance → Lens Calibration.
Image 10-37: Maintenance menu, Lens Calibration
The Lens Calibration menu is displayed.
Image 10-38: Lens Calibration menu
2. In the Lens Calibration menu, select the desired calibration action and click OK.
You can select one of the following functions:
• Horizontal shift
• Vertical shift
• Focus
• Zoom
The text Calibration in progress will be displayed next to selected function until the calibration is completed.
When an error is detected, the message Calibration Error is displayed next to function.
GUI – System Settings
