R5906112 /09 UDX series80
5.3 Test Patterns
How to use test patterns
1. In the main menu, select Test Patterns.
or
Push the Test Patterns button on the RC.
Image 5-5: Main menu, Test Patterns
2. In the Test Patterns menu, select either Internal, or Output test patterns.
3. In the chosen submenu, select the desired test pattern from the list.
You can select one of the following Internal test patterns:
• Color bars
• Checker board
• Blue / Green / Red / White
• Convergence
• Focus
• Aspect
• Scheimpflug White / Green
• Cross hatch
• Monoscope
• 3D Stereo
You can select one of the following Output test patterns:
• Blemish zone
• Checkerboard
• Color bars
• Convergence
• FIP
• Full screen black / white / blue / green / red / cyan / magenta / yellow
• Grid
• Horizontal Ramp
• Vertical Ramp
• MTF
4. To turn the test pattern off, return to the previous menu.
Graphic User Interface (GUI)
