C.2 Overview video timings SDI Inputs
Overview
The following standard video formats are available for the projector.
Video timing
(active pixels x active
lines)
Vertical refresh rate
(Hz)
9
Type Port Type
1280 x 720 24 HD-SDI Single Link & Quad Link
1280 x 720 25 HD-SDI Single Link & Quad Link
1280 x 720 30 HD-SDI Single Link & Quad Link
1280 x 720 50 HD-SDI Single Link & Quad Link
1280 x 720 60 HD-SDI Single Link & Quad Link
1920 x 1080 24 HD-SDI Single Link & Quad Link
1920 x 1080 25 HD-SDI Single Link & Quad Link
1920 x 1080 30 HD-SDI Single Link & Quad Link
1920 x 1080 50 3G-SDI Single Link & Quad Link
1920 x 1080 60 3G-SDI Single Link & Quad Link
1920 x 1200 50 3G-SDI “BarcoLink” Single Link & Quad Link
1920 x 1200 59.94 3G-SDI “BarcoLink” Single Link & Quad Link
1920 x 1200 60 3G-SDI “BarcoLink” Single Link & Quad Link
2048 x 1080 50 3G-SDI Single Link & Quad Link
2048 x 1080 60 3G-SDI Single Link & Quad Link
3840 x 2160 50 12G-SDI
10
Single Link
3840 x 2160 60 12G-SDI
10
Single Link
3840 x 2400 50 12G-SDI “BarcoLink
4k”
10
Single Link
3840 x 2400 59.94 12G-SDI “BarcoLink
4k”
10
Single Link
3840 x 2400 60 12G-SDI “BarcoLink
4k”
10
Single Link
4096 x 2160 50 12G-SDI
10
Single Link
4096 x 2160 60 12G-SDI
10
Single Link
Overview video timings for video interfaces
9: Support for refresh rates 24.00, 30.00 and 60.00 Hz automatically includes support of 1/1.001 x those refresh rates.
10: 12G SDI board only, and only on Channel A
