Barco UDX Series User Manual

R5906112 /09 UDX series 225
Resolution
Vertical
refresh rate
(Hz)
Compatible signal
HDMI 2.0
Inputs
12G SDI
Input on Mk
II Input
board &
Fiber
Network
Inputs
3G SDI
Inputs
DisplayPort
1.2 Inputs
HDBaseT &
HDMI 1.4
Inputs
2048 x 1080 48 X — — X X
2048 x 1080 50 X X X X X
2048 x 1080 60 X X X X X
2048 x 1080 120 — — — X —
2560 x 1600 50 X — — X X
2560 x 1600 60 X — — X X
2560 x 1600 120 — — — X —
3840 x 2160 24 X — — X X
3840 x 2160 25 X — — X X
3840 x 2160 30 X — — X X
3840 x 2160 50 X X — X —
3840 x 2160 60 X X — X —
3840 x 2400 50 X — — X —
3840 x 2400 60 X — — X —
4096 x 2160 24 X — — X X
4096 x 2160 25 X — — X X
4096 x 2160 30 X — — X X
4096 x 2160 50 X X — X —
4096 x 2160 60 X X — X —
Overview video timings for video interfaces
