Barco UDX Series

R5906112 /09 UDX series 201
Software tools Projector Toolset + Android* app + iOS* app
Control XLR wired + IR, RS232, Wifi* (opt), GSM* (opt)
Network connection 10/100 base-T, RJ-45 connection, Wifi* (optional)
Power requirements 120-160 V(reduced power) / 200-240 V (+/- 10%), 20 A, 50-60 Hz
Max. power consumption 1,900W @ 230 volts STBY<10W
Noise level (typical at 25°C/
77°F)
49 dB(A)
Operational ambient
temperature
0°-40°C/ 32°-104°F (45°C reduced power)
Operational humidity 0-80% (non condens)
Dissipation BTU Max. 6,600 BTU/h
Dimensions (WxLxH) 660 x 830 x 350 mm (25.98 x 32.67 x 13.77")
Shipping Dimensions (WxLxH) 980 x 1,200 x 760 mm (38.58 x 47.24 x 29.92")
Weight 87.5 kg (193 lbs)/shipping weight from factory: 105 kg (231 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1, complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
* Software upgradeable. Check with your local authorized Barco sales
representative for full details.
Specifications
