R5906112 /09 UDX series 203
Control XLR wired + IR, RS232, Wifi** (opt), GSM** (opt)
Network connection 10/100 base-T, RJ-45 connection, Wifi** (optional)
Power requirements 120-160 V (reduced power) / 200-240V (+/- 10%), 20A, 50-60Hz
Max. power consumption 3750W
Noise level (typical at 25°C/
77°F)
58dB(A)
Operational ambient
temperature
0-40°C / 32°-104°F (reduce power >35°C)
Operational humidity 0-80% (non condens)
Dissipation BTU Max. 12,795 BTU/h
Dimensions (WxLxH) 660 x 830 x 350 mm / 25.98 x 32.67 x 13.77 inches
Shipping Dimensions (WxLxH) 800 x 1,200 x 685 mm / 31.49 x 47.24 x 26.96 inches
Weight 92kg (202 lbs)/shipping weight from factory: 110kg (242 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
Specifications
