R5906112 /09 UDX series 209
Control XLR wired + IR, RS232, Wifi (opt)*, GSM (opt)*
Network connection 10/100 base-T, RJ-45 connection, Wifi (optional)*
Power requirements 120-160V (reduced power)/ 200-240V (+/- 10%), 20A, 50-60Hz (reduced
power on 110v)
Max. power consumption 1,900 W @ 230 volts/ STBY less than 10W
Noise level (typical at 25°C/
77°F)
49 dB(A)
Operational ambient
temperature
0°-40°C/ 32°-104°F (45°C reduced power)
Operational humidity 0-80% (non condens)
Dissipation BTU Max. 6,600 BTU/h
Dimensions (WxLxH) 660 x 830 x 350 mm (25.98 x 32.67 x 13.77")
Shipping Dimensions (WxLxH) 800 x 1,200 x 685 mm / 31.49 x 47.24 x 26.96 inches
Weight 87.5kg (193 lbs)/shipping weight from factory: 105kg (231 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
* Software upgradeable, please contact your local authorized Barco sales
representative
Specifications
