Barco UDX Series User Manual

R5906112 /09 UDX series230
Video timing
(active pixels x active
lines)
Vertical refresh rate
(Hz)
Available layout modes,
other than standard
layout (1 x 1 layout)
11
Support for 3D?
1920 x 1080 120 4 Quadrant mode (2 x 2
layout)
Active 3D
1920 x 1200 50
1920 x 1200 60
1920 x 1200 120 4 Quadrant mode (2 x 2
layout)
Active 3D
1920 x 2160 60 2 Column mode (2 x 1
layout)
Passive stereo
1920 x 2160 120 2 Column mode (2 x 1
layout)
Active 3D
1920 x 2400 60 2 Column mode (2 x 1
layout)
2048 x 1080 24
2048 x 1080 25
2048 x 1080 30
2048 x 1080 48
2048 x 1080 50
2048 x 1080 60
2048 x 1080 120 4 Quadrant mode (2 x 2
layout)
Active 3D
2048 x 2160 60 2 Column mode (2 x 1
layout)
2048 x 2160 120 2 Column mode (2 x 1
layout)
Active 3D
2560 x 1080 120 Active 3D
2560 x 1440 120 Active 3D
2560 x 1600 50
2560 x 1600 60
2560 x 1600 120
3840 x 2160 24
3840 x 2160 25
3840 x 2160 30
3840 x 2160 50
3840 x 2160 60 Passive Stereo
3840 x 2400 50
3840 x 2400 60
4096 x 2160 24
4096 x 2160 25
Overview video timings for video interfaces
11: Other layout modes are only available on Input boards that have multiple DP inputs.
