R5906112 /09 UDX series 239
Cha-
nnel
Function Value Default Actions
13 Light Source
Power
15
0 - 3 0 Set light source to 100%
4 - 7 Set light source to 95%
8 - 11 Set light source to 90%
12 - 15 Set light source to 85%
16 - 20 Set light source to 80%
21 - 23 Set light source to 75%
24 - 27 Set light source to 70%
28 - 31 Set light source to 65%
32 - 35 Set light source to 60%
36 - 39 Set light source to 55%
40 - 43 Set light source to 50%
44 - 47 Set light source to 45%
48 - 51 Set light source to 40%
52 - 55 Set light source to 35%
56 - 59 Set light source to 30%
60 - 63 Set light source to 25%
64 - 67 Set light source to 20%
68 - 71 Set light source to 15%
72 - 75 Set light source to 10%
76 - 79 Reserved for future functionality
80 - 87 Power on / Light source on (If held for 5 seconds)
88- 95 Power down / Light source off (if held for 5 seconds)
96 - 255 Reserved for future functionality
14 Various 0 - 7 0 Reserved for future functionality
8 - 15 Calibrate lens zoom & focus (if held for 5 seconds)
16 - 23 Calibrate lens horizontal and vertical shift (if held for 5 seconds)
24 - 31 Calibrate lens (zoom, focus and shift)
32 - 255 Reserved for future functionality
DMX chart
15: If the Light Source is forced to a output below its minimum value, it will remain at its minimum output value
