R5906112 /09 UDX series44
CAUTION: The HDBaseT inputs can bridge a distance of 100 m but are sensitive to radiated
electromagnetic interference: radiated electromagnetic interference (e.g. from GSM or switching
inductive or capacitive loads) within the limits of electromagnetic compatibility requirements of 3 V/
m can cause random flashes or temporary loss of the projected image.
As such, shielded CAT-6 cables with metal RJ-45 connectors are recommended; choose cable
length no longer than required and route HDBT cable optimally screened from possible sources of
electromagnetic emission.
Input specifications – HDBaseT inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
Pixel rate 25 – 297 MHz pixel clock
Color space • YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth • 24 bpp
• 30 bpp
• 36 bpp
HDCP support HDCP 1.x supported on HDBaseT Input 1
Network support Yes, on HDBaseT Input 1
For future release • 3D support
• Interlaced support
Audio not supported
Video timings
progressive
1
Layout mode Supported formats
Standard layout (1x1
layout)
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @25 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 2560 x 1600 @50 Hz
• Up to 2560 x 1600 @60 Hz
2 Column mode (2x1
layout)
• 1920 x 2160 @50 Hz
• 1920 x 2160 @60 Hz
• 2048 x 2160 @50 Hz
• 2048 x 2400 @60 Hz
Native video timings • UDX-U-series: 1600 x 1200 @60 Hz
• UDX-W-series: 1920 x 1200 @60 Hz
• UDX-4k-series: 3840 x 2160 @60 Hz
CAUTION: In order to display high resolution images (e.g.: 3840 x 2160 @60 Hz) via the DP1.2
input, the quality of the cable must be adequate, in addition the length of the cable can also
influence the performance. In case there is an issue with one of these criteria the automatic link-
training initiated by the DP-standard may decide to switch to a lower resolution.
Input specifications – DisplayPort 1.2 input
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
Pixel rate Up to 600 MHz pixel clock
Color space • YCbCr 4:2:2
Input & Communication
