Barcrest MPU6 - Class 6 Alarms

29
3.4.8 Class 6 alarms
These alarms are the result of faults detected with reel errors and are not applicable to the
Triple 7 cabinet.
When shown on the display these alarms range from 61 – 69 with Bacta code 20, 31, or 32.
Bacta Code Barcrest Group
No
Message
20 61 REEL UNIT MISSING
20 62 REEL UNIT FAILED
20 63 REEL UNIT RESET
20 64 REEL NOT RESET
20 65 REEL UNIT OLD VER
32 66 REEL DRV TR FAIL
31 67 REEL ENB TR FAIL
20 69 WRONG REEL TYPE
3.4.9 Class 7 alarms
These alarms are caused by coin input errors.
When shown on the display these alarms range from 70 – 7F with Bacta code 10, 12, 13, 14,
81 or 82.
Bacta Code Barcrest Group no Message
10 70 Serial Coin Mech
80 70 Coin Mech Jam
81 70 Coin Mech Fail
14 71 5p Coin Timing
14 72 5p Coin Locked
14 73 10p Coin Timing
14 74 10p Locked Out
13 75 20p Coin Timing
13 76 20p Locked Out
12 77 50p Coin Timing
12 78 50p Locked Out
11 79 PND Coin Timing
11 7A PND Coin Locked
11 7B 2PND Coin Timing
11 7C 2PND Coin Locked Out
82 7F Coin Mech Tamper
3.4.10 Class 8 alarms
These alarms are caused by coin hopper output errors.
When shown on the display these alarm 88 with Bacta code of 11 to 14.
Bacta Code Barcrest Group
No
Message
11 85 £1 Opto Blocked when idle
12 85 £1 Opto Blocked on payout
13 85 £1 Opto Flooded or s/c when idle
14 85 £1 Opto Flooded or o/c on payout
