Barcrest MPU6 - Dallas Key (UK Horizon Only)

71
5.2.9 Dallas Key (UK Horizon Only)
Pin Function
25 Ground
43 Hopper Dump
45 2
nd
Test
47 Refill
5.2.10 Fan Sense (Triple 7 Only)
Pin Function
40 Fan Sense
41 Fan Sense
42 Fan Sense
5.2.11 MPU6 Configuration IButton Cell (Horizon Only)
The horizon machine is fitted with an IButton cell that stores the machines configuration
information that includes the following:
• Hopper Balance
• IButton Information
• Option Switch Settings
5.2.12 MPU6 Ident IButton Cell (Horizon Only)
The horizon machine is fitted with an IButton cell that has the machines security Ident stored.
It replaces the security ident PIC device previously used on MPU5 technology. Without this
the machine will go into a characteriser error alarm.
