Barcrest MPU6 - Ardac Note (Acceptor Netplex)

70
5.2.5 Ardac Note (Acceptor Netplex)
Pin
Function
25 Ground
58 RX
59 TX
63 12V
5.2.6 Coin Mech
Pin Function
6 13V
19 Ground
45 CCtalk
5.2.7 Meters
Pin Function
8 13V
16 Ground
34 Meter Reset
35 Data Out
39 Meter Sense
60 Meter CLK
5.2.8 Dallas Key (Triple 7 only)
Pin Function
11 Hopper Dump
25 Ground
43 Test
45 Top Up
47 Refill
