5.3.4 MUX5(e) Pin listings

LAMPS1, LAMPS2 (in parallel)

Pin Signal Function Pin Signal Function

1 LAMP_HIGH_0 Drive line 10 LOW_SIDE_0 Select line

2 LAMP_HIGH_1 .. 11 LOW_SIDE_1 ..

3 LAMP_HIGH_2 .. 12 LOW_SIDE_2 ..

4 LAMP_HIGH_3 .. 13 LOW_SIDE_3 ..

5 LAMP_HIGH_4 .. 14 LOW_SIDE_4 ..

6 LAMP_HIGH_5 .. 15 LOW_SIDE_5 ..

7 Keyway 16 LOW_SIDE_6 ..

8 LAMP_HIGH_6 Drive line 17 LOW_SIDE_7 ..

9 LAMP_HIGH_7 ..

LAMPS3 connector

Pin Signal Function Pin Signal Function

1 LAMP_HIGH_8 Drive line 10 LOW_SIDE_0 Select line

2 LAMP_HIGH_9 .. 11 LOW_SIDE_1 ..

3 LAMP_HIGH_10 .. 12 LOW_SIDE_2 ..

4 LAMP_HIGH_11 .. 13 LOW_SIDE_3 ..

5 LAMP_HIGH_12 .. 14 LOW_SIDE_4 ..

6 LAMP_HIGH_13 .. 15 LOW_SIDE_5 ..

7 Keyway 16 LOW_SIDE_6 ..

8 LAMP_HIGH_14 Drive line 17 LOW_SIDE_7 ..

9 LAMP_HIGH_15 ..

LAMPS4 connector (MUX5E)

Pin Signal Function Pin Signal Function

1 LAMP_HIGH_16 Drive line 10 LOW_SIDE_0 Select line

2 LAMP_HIGH_17 .. 11 LOW_SIDE_1 ..

3 LAMP_HIGH_18 .. 12 LOW_SIDE_2 ..

4 LAMP_HIGH_19 .. 13 LOW_SIDE_3 ..

5 LAMP_HIGH_20 .. 14 LOW_SIDE_4 ..

6 LAMP_HIGH_21 .. 15 LOW_SIDE_5 ..

7 Keyway 16 LOW_SIDE_6 ..

8 LAMP_HIGH_22 Drive line 17 LOW_SIDE_7 ..

9 LAMP_HIGH_23 ..
