BE1-11m RTD Module
RTD module connections are made with one 6-position connector, two 12-position connectors, and two
15-position connectors. Connector screw terminals accept a maximum wire size of 12 AWG (3.31 mm
2
).
Maximum screw torque is 5 inch-pounds (0.56 N•m) for the 12- and 15-position connectors. Maximum
screw torque is 9 inch-pounds (1.01 N•m) for the 6-position connector.
Operating Power
The RTD module operating power input accepts 125/250 Vac/dc and tolerates voltage over the range of
90 to 270 Vac or 90 to 300 Vdc. The operating power inputs are not polarity sensitive. Operating power
terminals are listed in Table 83-1.
Table 83-1. Operating Power Terminals
Chassis ground connection
Alarm Contacts
These terminals provide form C (SPDT) alarm contacts. Alarm contact terminals are listed in Table 83-2.
Table 83-2. Alarm Contact Terminals
RTD Module Inputs and Outputs
Input and output terminals are shown in Figure 83-2 and listed in Table 83-3.
