Baumuller b maXX BM4 Series Compact Manual

Error detection and troubleshooting
Compact manual b maXX
®
BM4400, BM4600, BM4700
Document no.: 5.06014.02
73
of 94
8
Error drive manager P0211
Error no. Meaning Reaction Troubleshooting
160 Timeout communication adjustable Remove the timeout of the
Proprog communication
161 Timeout BACI adjustable Remove the timeout of the BACI communica-
tion option module
162 Timeout cyclic communication adjustable Remove the timeout of the
cyclic communication:
163 Timeout required data adjustable Remove the timeout of the required data com-
munication
164 Field bus error adjustable Check the field bus communication
165 Controller not synchronous to external
signal
adjustable set the Sync-Offset and / or
Sync-tolerance
166 Error at brake control IS Check the wiring and the function of the brake
167 No release of holding brake when start-
ing the drive
IS Check the holding brake
168 No closing of holding brake at stopping
of drive
adjustable Check the holding brake
169 Error holding brake status (cyclic moni-
toring)
adjustable Check the holding brake
170 Error holding brake lining adjustable Check the holding brake
171 Initialize holding brake error IS Check, if there is a DIO module, if it is in the
correct position and if it is correctly parameter
-
ized (also see P0883)
172 Error holding brake: holding torque not
reached
IS Ensure that the torque limits are not set too
small
|P1402| < Min (|P1036|, |P1037|, |P1038|)
173 to 175 reserved
not assigned = 0
