Three-phase synchronous motors DSC1-045-100
DSC1-045-100
11/2016
Technical alterations reserved
Baumüller Nürnberg GmbH
17
DSC1-071..64 W.. (water cooled)
3 AC 400 V mains voltage for converters with unregulated supply
Motor type
Nom.
speed
Stand-
still
torque
1)
Stand-
still
current
1
)
max.
static
torque
Max.
static
current
Rated
out-
put
1)
Rated
torque
1)
Rated
current
1)
Voltage
constant
Rated
fre-
quency
Rotor
inertia
(motor)
2)
Weight
3)
n
N
M
0
I
0
M
0.max
I
0.max
P
N
M
N
I
N
k
E/cold
f
N
J
m
min
-1
Nm
A
Nm
A
kW
Nm
A
V/
10001/min
Hz
kgcm
2
kg
DSC1-071KO64W-10-54
900
20
5.4
27
8.6
1.8
20
5.4
260
75.0
12.6
11.7
DSC1-071SO64W-10-54
750
39
9.1
55
14.7
3.0
39
9.1
303
62.5
21.8
16.1
DSC1-071MO64W-10-54
800
58
12.8
82
20.9
4.8
57
12.7
320
66.7
31.1
20.4
DSC1-071KO64W-20-54
1800
20
10.0
27
15.9
3.6
19
9.9
140
150.0
12.6
11.7
DSC1-071SO64W-20-54
1600
39
17.3
55
27.8
6.4
38
17.0
160
133.3
21.8
16.1
DSC1-071MO64W-20-54
1600
58
24.1
82
39.3
9.5
57
23.6
170
133.3
31.1
20.4
DSC1-071KO64W-30-54
2700
20
14.2
27
22.7
5.4
19
13.9
98.2
225.0
12.6
11.7
DSC1-071SO64W-30-54
2400
39
25.9
55
41.8
9.5
38
25.2
107
200.0
21.8
16.1
DSC1-071MO64W-30-54
2400
58
34.8
82
57
14.0
56
33.6
117
200.0
31.1
20.4
DSC1-071KO64W-40-54
3600
20
19.1
27
30.4
7
19
18.1
73.2
300
12.6
11.7
DSC1-071SO64W-40-54
3100
39
31.9
55
51
12
37
30.5
86.5
258.3333
21.8
16.1
1)
Coil overtemperature ∆ T < 105K; direct flange mounting (mounting plate 450 x 400 x 30 mm)
2)
Rotor inertia moment with PE brake: +7.9 kgcm²
3)
Weight with PE brake: +3.0 kg
