Baumuller DSC1-045-100 Series - 3.5. Encoder Cables for b maXX 5000

Three-phase synchronous motors DSC1-045-100
DSC1-045-100
11/2016
Technical alterations reserved
Baumüller Nürnberg GmbH
45
Encoder cables for EnDat® 2.2 - prefabricated cables with plug connector
Dragable, prefabricated
cable 1x4x0.14 + 4x0.34 PUR Ø 6mm with plug
connector
Length in m
Item Number
Item Number (Speed Tec)
2
434056
459031
3
434057
459032
5
434058
459033
10
434059
459035
15
434060
459036
20
434061
459037
25
434062
459038
50
434063
459042
3.5. Encoder cables for b maXX 5000
A prefabricated encoder cable is used for all encoder systems. The connection at the motor end consists of a
12-pole circular signal connector on resolvers and Hyperface® encoder, a 17-pole circular signal connector on
ECN1313/EQN1325. The connection at the controller side consists of a 26-pole D-Sub connector. Alternatively,
the signal connector on the motor side is available in a Speed-Tec version.
3.5.1. Technical data
Technical description - dragable for resolver
Li9YC, 1 x (2 x 0,25) + Li9Y, 2 x (2x0,25) + Li9YC11Y, 1 x (2 x 0,34), copper strand, twisted pairs
PUR sheat, green; inscription with Baumüller Nürnberg and encoder cable Resolver
1st side: 12-pole circular signal plug connector with 12 socket contacts
2nd side: 26-pole D-Sub plug connector with pin contacts and locking screws 4-40UNC
Outer diameter 7.3 mm (+/- 0.3mm)
Bending radius: r 4 x D (fixed routing), r 10 x D (flexible use)
Technical description - dragable for SinCos Hiperface®-interface und SinCos - and TTL - incremental
encoder
Li9YC, 3 x (2 x 0,25) , + Li9Y, 3 x (2 x 0,25) + Li9YC11Y, 1 x (2x0,34), copper strand, twisted pairs
PUR sheat, green; inscription with Baumüller Nürnberg and encoder cable Hyperface or Incremental
1st side: 12-pole circular signal plug connector with 12 socket contacts
2nd side: 26-pole D-Sub plug connector with pin contacts and locking screws 4-40UNC
Outer diameter 9.6 mm (+/- 0.3mm)
Bending radius: r 4 x D (fixed routing), r 10 x D (flexible use)
Technical description – dragable for EnDat® 2.1-interface
Li9YC, 3 x (2 x 0,25) , + Li9Y, 3 x (2 x 0,25) + Li9YC11Y, 1 x (2x0,34), copper strand, twisted pairs
PUR sheat, green; inscription with Baumüller Nürnberg and encoder cable Endat 2.1
1st side: 17-pole circular signal plug connector with 17 socket contacts
2nd side: 26-pole D-Sub plug connector with pin contacts and locking screws 4-40UNC
Outer diameter 9.6 mm (+/- 0.3mm)
Bending radius: r 4 x D (fixed routing), r 10 x D (flexible use)
