Three-phase synchronous motors DSC1-045-100
Technical alterations reserved
11/2016
DSC1-045-100
16
Baumüller Nürnberg GmbH
2.3. DSC1-071
DSC1-071..64 U.. (without fan)
3 AC 400 V mains voltage for converters with unregulated supply
Motor type
Nom.
speed
Stand-
still
torque
1)
Stand-
still
current
1
)
max.
static
torque
Max.
static
current
Rated
out-
put
1)
Rated
torque
1)
Rated
current
1)
Voltage
constant
Rated
fre-
quency
Rotor
inertia
(motor)
2)
Weight
3)
n
N
M
0
I
0
M
0.max
I
0.max
P
N
M
N
I
N
k
E/cold
f
N
J
m
min
-1
Nm
A
Nm
A
kW
Nm
A
V/
10001/min
Hz
kgcm
2
kg
DSC1-071K64U10-5
1000
12
3.1
27
8.6
1.2
12
3.1
260
83.3
12.6
11.5
DSC1-071S64U10-5
1000
22
4.8
55
14.7
2.2
21
4.7
303
83.3
21.8
16.5
DSC1-071M64U10-5
1000
29
6
82
20.9
2.9
27
5.8
320
83.3
31.1
21.5
DSC1-071K64U20-5
2000
12
5.8
27
15.9
2.3
11
5.4
140
166.7
12.6
11.5
DSC1-071S64U20-5
2000
22
9.1
55
27.8
4.0
19
8.3
160
166.7
21.8
16.5
DSC1-071M64U20-5
2000
29
11.4
82
39.3
5.1
24
9.8
170
166.7
31.1
21.5
DSC1-071K64U30-5
3000
12
8.3
27
22.7
3.1
10
7.0
98.2
250.0
12.6
11.5
DSC1-071S64U30-5
3000
22
13.7
55
41.8
5.2
16
10.6
107
250.0
21.8
16.5
DSC1-071M64U30-5
3000
29
16.4
82
57
6.2
20
11.7
117
250.0
31.1
21.5
DSC1-071K64U40-5
4000
12
11.1
27
30.4
3.6
8.6
8.2
73.2
333.3
12.6
11.5
DSC1-071S64U40-5
4000
22
16.8
55
51
5.2
12
10.1
86.5
333.3
21.8
16.5
1)
Coil overtemperature ∆ T < 105K; direct flange mounting (mounting plate 450 x 400 x 30 mm³)
2)
Rotor inertia moment with PE brake: +7.9 kgcm²
3)
Weight with PE brake: +3.0 kg
DSC1-071..64 O.. (with fan)
3 AC 400 V mains voltage for converters with unregulated supply
Motor type
Nom.
speed
Stand-
still
torque
1)
Stand-
still
current
1
)
max.
static
torque
Max.
static
current
Rated
out-
put
1)
Rated
torque
1)
Rated
current
1)
Voltage
constant
Rated
fre-
quency
Rotor
inertia
(motor)
2)
Weight
3)
n
N
M
0
I
0
M
0.max
I
0.max
P
N
M
N
I
N
k
E/cold
f
N
J
m
min
-1
Nm
A
Nm
A
kW
Nm
A
V/
10001/min
Hz
kgcm
2
kg
DSC1-071K64O10-5
1000
16
4.2
27
8.6
1.6
15
4.1
260
83.3
12.6
15
DSC1-071S64O10-5
900
29
6.5
55
14.7
2.7
29
6.6
303
75.0
21.8
20
DSC1-071M64O10-5
900
40
8.5
82
20.9
3.6
39
8.2
320
75.0
31.1
25
DSC1-071K64O20-5
2000
16
7.7
27
15.9
3.1
15
7.4
140
166.7
12.6
15
DSC1-071S64O20-5
1800
29
12.4
55
27.8
5.3
28
12.1
160
150.0
21.8
20
DSC1-071M64O20-5
1800
40
16
82
39.3
7.0
37
14.9
170
150.0
31.1
25
DSC1-071K64O30-5
2900
16
11
27
22.7
4.4
14
10.2
98.2
241.7
12.6
15
DSC1-071S64O30-5
2800
29
18.6
55
41.8
7.5
26
16.6
107
233.3
21.8
20
DSC1-071M64O30-5
2700
40
23.1
82
57
10.0
35
20.7
117
225.0
31.1
25
DSC1-071K64O40-5
3900
16
14.8
27
30.4
5.6
14
13.1
73.2
325.0
12.6
15
DSC1-071S64O40-5
3600
29
22.8
55
51
8.7
23
18.3
86.5
300.0
21.8
20
1)
Coil overtemperature ∆ T < 105K; direct flange mounting (mounting plate 450 x 400 x 30 mm)
2)
Rotor inertia moment with PE brake: +7.9 kgcm²
3)
Weight with PE brake: +3.0 kg
