Three-phase synchronous motors DSC1-045-100
DSC1-045-100
11/2016
Technical alterations reserved
Baumüller Nürnberg GmbH
43
Technical description - dragable for EnDat® 2.1-interface
Li12YC11Y, 5x (2x0.14mm²) + 2 x 0.5mm² copper strand, twisted pairs
PU sheath, black; inscription with Baumüller logo, white
1st side: 17-pole circular signal plug connector with 17 socket contacts
2nd side: 15-pole D-Sub plug connector with pin contacts and locking screws 4-40UNC
Outer diameter 9.0 mm (+/- 0.3mm)
Bending radius: r 70 mm (fixed routing), r 100 mm (flexible use)
Nominal voltage: 300V
AC
Technical description - dragable for EnDat® 2.2-interface
PUR sheath, 1x(4x0.14mm²) + (4x0.34mm²)
1 twisted foursome 0.14mm
2
, 4 wires 0.34mm
2
, copper, tin-plated
Total shield CuSn, inscription Heidenhain
1st side: 9-pole circular signal plug connector with 8 socket contacts
2nd side: 15-pole D-Sub plug connector with pin contacts and locking screws 4-40UNC
Outer diameter 6.0 mm
Bending radius: r 20 mm (fixed routing), r 75 mm (flexible use)
Dielectric strength wire/wire and wire/shield: 0.5kV at 50Hz, 1 minute
3.4.2. Application references
Operating temperature of encoder cable resolver/ SinCos Hiperface®-interface /
SinCos - and TTL - incremental encoder / EnDat® 2.1
Dragable
Not dragable
Limit temperature
on the surface
on the surface
Static use/minimal movement
- 40 °C to + 80 °C
- 30 °C to + 80 °C
Permanent movement
- 30 °C to + 80 °C
- 5 °C to + 70 °C
Operating temperature of encoder cable EnDat® 2.2
Dragable
Limit temperature
on the surface
Static use/minimal movement
- 40 °C to + 80 °C
Permanent movement
- 10 °C to + 80 °C
Routing of cable on motor
The cables must not touch the surface of the motor.
