Three-phase synchronous motors DSC1-045-100
DSC1-045-100
11/2016
Technical alterations reserved
Baumüller Nürnberg GmbH
11
1.6. Explanation of motor data
n
N
Rated speed [rpm]
M
0
Nominal torque [Nm] with speeds ≥ 1 [rpm] without time limit
I
0
nominal current [A] with speeds ≥ 1 [rpm] without time limit, I
0
is the r.m.s. value
M
0,max
Maximum static torque [Nm] with maximum current [A] and speed = 0, momentarily
I
0,max
Static current [A] at M
o, max
; I
0max
is the effective value
P
N
Rated output [kW] with M
N
and n
N
(see Performance definition)
M
N
Rated torque [Nm]
I
N
Rated effective current [A]
k
E / cold
Voltage constant (EMF) to [V per 1000 rpm]
f
N
Rated frequency [Hz]
J
Rotor inertia incl. resolver without holding brake [kgm²]
m
Motor mass [kg]
When the converter is operating, the specified rated outputs and torques at the rated speed are achieved with
a clocking frequency of 4 kHz in the power divider. We recommend a cycle frequency of 6 kHz.
All converters scheduled for use must have the option of field weakening as a mandatory requirement.
The sizemaXX drive configurator is available at www.baumueller.de for designing the motors and the overall
drive system.
1.7. Type key
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Type
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Overall size 总尺寸
045
056
071
100
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
全长
KO
SO
MO
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
保护程度
64 - Degree of protection IP64
65 - Degree of protection IP65
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
冷却类型
U - Without fan
O - With fan, 230 VAC supply voltage
W – Water cooling
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
额定速度等级
10 - 1000 rmp
20 - 2000 rmp
30 - 3000 rmp
40 - 4000 rmp
