Technical description – Draggable hybrid cable for Hiperface DSL®
Hybrid cable
Shielding braid Copper wires, tinned
PUR sheath, orange, flame-retardant, self-extinguishing
1st side: metal round plug speedtec M23 hybrid socket 8-pole for wire with 4G1.5 and 4G2.5
metal round plug speedtec M40 hybrid socket 5+4-pole + 2 -pole insulating body for wire with
4G2.5, 4G4 and 4G6
2nd side: Metal 45°-D-Sub plug, 26-pole with electronics
Ready-for-use cable for bmaXX 5300
Cable for bmaXX 5500 being prepared
3.5.2. Application references
Operating temperature of encoder cable resolver/ SinCos Hiperface®-interface / SinCos - and TTL -
incremental encoder / EnDat® 2.1
Limit temperature
on the surface
Static use/minimal movement
- 40 °C to + 80 °C
Permanent movement
- 20 °C to + 60 °C
Routing of cable on motor
The cables must not touch the surface of the motor.
3.5.3. Order information for encoder cables
Encoder cable - prefabricated with plug
For resolver
For SinCos Hiperface® - interface
Length in
m
Item Number
Item Number (Speed
Tec)
Length in m
Item
Number
Art. Nr. (Speed Tec)
1
429914
448746
1
429958
448761
2
429915
448747
2
429959
448762
3
429916
448748
3
429960
448763
5
429917
448749
5
429961
448764
7
429918
448750
7
429962
448765
10
429919
448751
10
429963
448766
15
429920
448752
15
429964
448767
20
429921
448753
20
429965
448768
25
429922
448754
25
429966
448769
30
429923
448755
30
429967
448770
35
429924
448756
35
429968
448772
40
429925
448757
40
429969
448773
50
429926
448758
50
429970
448774
75
429927
448759
75
429971
448775
For SinCos - and TTL - incremental encoder
For SinCos EnDat® 2.1 - interface
Length in
m
Item Number
Item Number (Speed
Tec)
Length in m
Item
Number
Item Number (Speed Tec)
1
430015
448777
1
429986
448796
2
430016
448778
2
429987
448797
3
430017
448779
3
429988
448798
