Baumuller DSC1-045-100 Series User Manual

Three-phase synchronous motors DSC1-045-100
Technical alterations reserved
11/2016
DSC1-045-100
18
Baumüller Nürnberg GmbH
2.4. DSC1-100
DSC1-100..64 U.. (without fan)
3 AC 400 V mains voltage for converters with unregulated supply
Motor type
Nom.
speed
Stand-
still
torque
1)
Stand-
still
current
1
)
max.
static
torque
Max.
static
current
Rated
out-
put
1)
Rated
torque
1)
Rated
current
1)
Voltage
constant
Rated
fre-
quency
Rotor
inertia
(motor)
2)
Weight
3)
n
N
M
0
I
0
M
0.max
I
0.max
P
N
M
N
I
N
k
E/cold
f
N
J
m
min
-1
Nm
A
Nm
A
kW
Nm
A
V/
10001/min
Hz
kgcm
2
kg
DSC1-100KO64U-10-54
1000
23
6.9
42
14.5
2.3
22
6.4
231
83.3
45.8
18.5
DSC1-100SO64U-10-54
1000
43
9.9
85
22.8
4.2
40
9.2
295
83.3
73.5
25.7
DSC1-100MO64U-10-54
1000
59
13
125
33.2
5.8
55
12.1
304
83.3
101.2
33.0
DSC1-100KO64U-20-54
2000
23
13.4
42
28.3
4.0
19
10.9
119
166.7
45.8
18.5
DSC1-100SO64U-20-54
2000
43
19.5
84
44.9
7.5
36
16.0
150
166.7
73.5
25.7
DSC1-100MO64U-20-54
2000
59
25
125
64
10.0
48
20.1
158
166.7
101.2
33.0
DSC1-100KO64U-30-54
3000
23
19
42
40.2
4.8
15
12.3
83.6
250.0
45.8
18.5
DSC1-100SO64U-30-54
3000
43
27.7
84
64
9.3
29
18.8
106
250.0
73.5
25.7
1)
Coil overtemperature ∆ T < 105K; direct flange mounting (mounting plate 450 x 400 x 30 mm)
If you are using a DSC100..64U.. with absolute value signal encoders, you need to reduce the torques by 1.0 Nm (DSC 100 K),
2.0 Nm (DSC 100 S) or 3.0 Nm (DSC 100 M).
2)
Rotor inertia moment with PE brake: +17.6 kgcm²
3)
Weight with PE brake: +6.0 kg
DSC1-100..64 O.. (with fan)
3 AC 400 V mains voltage for converters with unregulated supply
Motor type
Nom.
speed
Stand-
still
torque
1)
Stand-
still
current
1
)
max.
static
torque
Max.
static
current
Rated
out-
put
1)
Rated
torque
1)
Rated
current
1)
Voltage
constant
Rated
fre-
quency
Rotor
inertia
(motor)
2)
Weight
3)
n
N
M
0
I
0
M
0.max
I
0.max
P
N
M
N
I
N
k
E/cold
f
N
J
m
min
-1
Nm
A
Nm
A
kW
Nm
A
V/
10001/min
Hz
kgcm
2
kg
DSC1-100KO64O-10-54
1000
27
8.1
42
14.5
2.7
26
7.8
231
83.3
45.8
22.4
DSC1-100SO64O-10-54
900
53
12.3
85
22.8
4.7
49
11.4
295
75.0
73.5
29.6
DSC1-100MO64O-10-54
900
79
17.6
125
33.2
7.0
74
16.6
304
75.0
101.2
36.9
DSC1-100KO64O-20-54
2000
27
15.8
42
28.3
5.2
25
14.4
119
166.7
45.8
22.4
DSC1-100SO64O-20-54
1800
53
24.2
84
44.9
8.4
45
20.2
150
150.0
73.5
29.6
DSC1-100MO64O-20-54
1800
79
33.8
125
64
12.7
68
29.3
158
150.0
101.2
36.9
DSC1-100KO64O-30-54
3000
27
22.5
42
40.2
7.3
23
18.9
83.6
250.0
45.8
22.4
DSC1-100SO64O-30-54
2800
53
34.3
84
64
11.0
38
24.3
106
233.3
73.5
29.6
1)
Coil overtemperature ∆ T < 105K; direct flange mounting (mounting plate 450 x 400 x 30 mm)
2)
Rotor inertia moment with PE brake: +17.6 kgcm²
3)
Weight with PE brake: +6.0 kg
