Baumuller DSC1-045-100 Series User Manual

Three-phase synchronous motors DSC1-045-100
DSC1-045-100
11/2016
Technical alterations reserved
Baumüller Nürnberg GmbH
19
DSC1-100..64 W.. (water cooled)
3 AC 400 V mains voltage for converters with unregulated supply
Motor type
Nom.
speed
Stand-
still
torque
1)
Stand-
still
current
1
)
max.
static
torque
Max.
static
current
Rated
out-
put
1)
Rated
torque
1)
Rated
current
1)
Voltage
constant
Rated
fre-
quency
Rotor
inertia
(motor)
2)
Weight
3)
n
N
M
0
I
0
M
0.max
I
0.max
P
N
M
N
I
N
k
E/cold
f
N
J
m
min
-1
Nm
A
Nm
A
kW
Nm
A
V/
10001/min
Hz
kgcm
2
kg
DSC1-100KO64W-10-54
1000
34
10.5
42
14.5
3.5
33
10.3
231
83.3
45.8
21.2
DSC1-100SO64W-10-54
850
69
17.0
85
22.8
6.1
68
16.6
295
70.8
73.5
29.2
DSC1-100MO64W-10-54
850
105
25.5
125
33.2
9.3
105
25.0
304
70.8
101.2
37.2
DSC1-100KO64W-20-54
2000
34
20.4
42
28.3
6.8
32
19.5
119
166.7
45.8
21.2
DSC1-100SO64W-20-54
1800
69
33.5
84
44.9
13.0
67
32.0
150
150.0
73.5
29.2
DSC1-100MO64W-20-54
1700
105
48.9
125
64
18.0
100
46.7
158
141.7
101.2
37.2
DSC1-100KO64W-30-54
3000
34
29
42
40.2
10.0
32
27.2
83.6
250.0
45.8
21.2
DSC1-100SO64W-30-54
2600
69
47.4
84
64
18.0
65
44.4
106
216.7
73.5
29.2
1)
Coil overtemperature ∆ T < 105K; direct flange mounting (mounting plate 450 x 400 x 30 mm)
2)
Rotor inertia moment with PE brake: +17.6 kgcm²
3)
Weight with PE brake: +6.0 kg
