3.4. Encoder cables for b maXX 4000
General Information
A prefabricated encoder cable is used for all encoder systems. The connection at the motor end consists of a
12-pole circular signal connector on resolvers and Hyperface® – encoders, a 17-pole circular signal connector
on ECN1313/EQN1325 and a 9-pole circular signal connector on ECN1325/EQN1337. The connection at the
controller side consists of a 15-pole D-Sub connector. Alternatively, the signal connector on the motor side is
available for Speed-Tec versions with trailing cables.
The dragable cable is suitable for mobile applications such as drag chains, for example. Unlike non-dragable
cables made from PVC, the cable sheath is made from durable PU (suitable for environments where acids and
bases are present).
3.4.1. Technical data
Technical description - non-dragable for resolver/ SinCos Hiperface®-interface / SinCos - and TTL -
incremental encoder
LiYCY, 5x (2x0.14mm²) + 2 x 0.5mm² copper strand, twisted pairs
PVC sheath, grey; inscription with Baumüller logo, black
1st side: 12-pole circular signal plug connector with 12 socket contacts
2nd side: 15-pole D-Sub plug connector with pin contacts and locking screws 4-40UNC
Outer diameter 9.0 mm (+/- 0.3mm)
Bending radius: r 60 mm (fixed routing), r 135 mm (flexible use)
Nominal voltage: 250V
AC
Technical description - dragable for resolver/ SinCos Hiperface®-interface / SinCos - and TTL -
incremental encoder
Li12YC11Y, 5x (2x0.14mm²) + 2 x 0.5mm² copper strand, twisted pairs
PU sheath, black; inscription with Baumüller logo, white
1st side: 12-pole circular signal plug connector with 12 socket contacts
2nd side: 15-pole D-Sub plug connector with pin contacts and locking screws 4-40UNC
Outer diameter 9.0 mm (+/- 0.3mm)
Bending radius: r 70 mm (fixed routing), r 100 mm (flexible use)
Nominal voltage: 300V
AC
Technical description - non-dragable for EnDat® 2.1-interface
LiYCY, 5x (2x0.14mm²) + 2 x 0.5mm² copper strand, twisted pairs
PVC sheath, grey; inscription with Baumüller logo, black
1st side: 17-pole circular signal plug connector with 17 socket contacts
2nd side: 15-pole D-Sub plug connector with pin contacts and locking screws 4-40UNC
Outer diameter 9.0 mm (+/- 0.3mm)
Bending radius: r 60 mm (fixed routing), r 135 mm (flexible use)
Nominal voltage: 250V
AC
