3.6.5. Ordering data for main connection cables
Rated current: 15 A
Rated current: 28 A
Cable 4 x 1,5 mm² + 4 x 0,75 mm²
Cable 4 x 4 mm² + 4x 0,75 mm²
With connector size 1
With connector size 1,5
Length in m
Item Number
Item Number Speed Tec
Length in m
Item Number
Item Number Speed Tec
5
324781
445872
5
326589
448063
7
324782
445887
7
326591
448064
10
324783
445889
10
326592
448065
15
324784
447675
15
326593
448066
20
324785
447676
20
326594
448067
25
324786
447677
25
326596
448069
30
324787
447678
30
326597
448070
35
324788
447679
35
326598
448071
40
324789
447680
40
326599
448072
50
324790
447681
75
324791
447682
100
324792
447683
Rated current: 20 A
Rated current 36 A
Cable 4 x 2,5 mm² + 4x 0,75 mm²
Cable 4 x 6 mm² + 4x 0,75 mm²
With connector size 1
With connector size 1,5
Length in m
Item Number
Item Number Speed Tec
Length in m
Item Number
Item Number Speed Tec
5
414840
447684
5
326600
448080
7
380967
447687
7
326601
448118
10
413410
447688
10
326602
448119
15
414841
447692
15
326603
448120
20
414842
447698
20
326604
448121
25
414843
447852
25
326605
448122
30
414846
447853
30
326606
448123
35
414848
447854
35
326607
448124
40
414849
447855
40
326608
448125
50
414850
447856
75
414851
447857
100
414852
447858
Rated current: 21 A
Rated current: 50 A
Cable 4 x 2,5 mm² + 4x 0,75 mm²
Cable 4 x 10 mm² + 4x 0,75 mm²
With connector size 1,5
With connector size 1,55
Length in m
Article number
Item Number Speed Tec
Length in m
Article number
Item Number Speed Tec
5
326577
447686
5
326609
448129
7
326578
447689
7
326610
448131
10
326579
447690
10
326611
448132
15
326580
447691
15
326612
448133
20
326581
447693
20
326613
448134
25
326582
447694
25
326614
448135
30
326583
447695
30
326615
448136
35
326584
447696
35
326616
448137
40
326585
447697
40
326617
448138
50
326586
447699
75
326587
448060
100
326588
448061
Mating plug
Type
Article number
Art, Nr, Speed Tec
Gr, 1 f, 4x1,5mm2 o, x2,5mm2
261740
445486
Gr, 1,5 f, 4x2,5mm2 bis 4x6mm2
326574
445487
Gr, 1,5 f, 4x10mm2
326569
445488
