Baumuller DSC1-045-100 Series User Manual

Three-phase synchronous motors DSC1-045-100
Technical alterations reserved
11/2016
DSC1-045-100
12
Baumüller Nürnberg GmbH
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Uzk_ DC
54 - 540 V
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Encoder type
O – No encoder
A - Resolver
B - SEK52
C - SEL52
D - SRS50
E - SRM50
F - ECN1313
G - EQN1325
H - ECN1325
I - EQN1337
M - Resolver (Safety)
N - SRS50-S (Safety)
Q - SRM50-S (Safety)
S - SKS36-S (Safety)
U - SKM36-S (Safety)
X - EQI1331
Y - ECI1319
5 - ECN1325-S (Safety)
6 - EQN1337-S (Safety)
g - EFS50 Hiperface DSL (21 bit)
h - EFM50 Hiperface DSL (21 bit)
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Brake
O – Without brake
B – With PE-brake
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Shaft options
A - Smooth shaft
B - With parallel key
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Main connection type
K – Terminal box (with KTY)
T – Terminal box (KTY on encoder socket)
M – Terminal box (with PT1000)
N – Terminal box (PT1000 on encoder socket)
S – Terminal box M23-thread
(KTY on main connection)
P – Connector socket M23-thread
(KTY on encoder socket)
G – Connector socket speedtec
(KTY on main connection)
H – Connector socket speedtec
(KTY on encoder socket)
B – Connector socket speedtec
(PT1000 on main connection)
D – Connector socket speedtec
(PT1000 on the encoder socket)
