Three-phase synchronous motors DSC1-045-100
DSC1-045-100
11/2016
Technical alterations reserved
Baumüller Nürnberg GmbH
13
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Main outlet port
T - Top
L - Left with a view toward D-side on shaft end
R - Right with a view toward D-side on shaft end
D - DE (D-side)
N - NDE (N-side)
P - Pivoted
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Encoder connection outlet
O – Without encoder
L - Left with a view toward D-side on shaft end
R - Right with a view toward D-side on shaft end
D - DE (D-side)
N - NDE (N-side)
P – Pivoted
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Bearing
K - Ball bearing D-side
R - Roller bearing D-side
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Vibration level
A - Vibration level A
B - Vibration level B
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
True running
N - Normal
R - Reduced
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Gear box / pump mounting
O - Without transmission mount and without pump
mounting
A - BPE - Gear box
B - BPEF - Gear box
C - BPEA - Gear box
D - BPN - Gear box
E - BPNA - Gear box
F - BPNF - Gear box
G - BPV - Gear box
H - BPVF - Gear box
DSC1-XXXXXXXX-XX-XX-XXX-XXX-X-XX-X-XXX
Special version
000 - No special version
AJ1 - Water connection with connector
OS1 – Fan with 115 VAC supply voltage
OS2 - Fan with 24 VDC supply voltage
XXX - Special version (internal coding)
Special coding is made alphanumeric
Example configuration: DSC1-071SO64O-10-54-AOA-BPP-K-AN-O-000
