86 AD6 InOut 4~16mA,SRPU
Microcontroller address/data 6
85 AD5 InOut 4~16mA,SRPU
Microcontroller address/data 5
84 AD4 InOut 4~16mA,SRPU
Microcontroller address/data 4
83 AD3 InOut 4~16mA,SRPU
Microcontroller address/data 3
82 AD2 InOut 4~16mA,SRPU
Microcontroller address/data 2
80 AD1 InOut 4~16mA,SRPU
Microcontroller address/data 1
79 AD0 InOut 4~16mA,SRPU
Microcontroller address/data 0
92 IOA 0 InOut 4~16mA,SRPU
Microcontroller address
77 IOA 1 InOut 4~16mA,SRPU
Microcontroller address 1/ IO
56 IOA 2 InOut 4~16mA,SRPU
Microcontroller address 2/ IO
57 IOA 3 InOut 4~16mA,SRPU
Microcontroller address 3/ IO
58 IOA 4 InOut 4~16mA,SRPU
Microcontroller address 4/ IO
59 IOA 5 InOut 4~16mA,SRPU
Microcontroller address 5/ IO
60 IOA 6 InOut 4~16mA,SRPU
Microcontroller address 6/ IO
61 IOA 7 InOut 4~16mA,SRPU
Microcontroller address 7/ IO
67 A16 InOut 4~16mA,SRPU
Flash address 16
91 A17 InOut 4~16mA,SRPU
Flash address 17
63 A18
InOut 4~16mA,
SRPD,SMT
Flash address 18 /IO
64 A19
InOut 4~16mA,
SRPD,SMT
Flash address 19 /IO
75 A20
YUV0 InOut 4~16mA,
SRPD,SMT
5) Flash address 20 /IO
6) While External Flash size <= 1MB:
I) Alternate digital video YUV output 0
87 A21
YUV7
GPIO
InOut 4~16mA,
SRPD,SMT
7) Flash address 21 /IO
8) While External Flash size <= 2MB:
I) Digital video YUV output 7 II) GPIO
88 ALE
InOut 4~16mA,
SRPD,SMT
Microcontroller address latch enable
78 IOOE#
InOut 4~16mA,
SRPD,SMT
Flash output enable, active low / IO
66 IOWR#
InOut 4~16mA,
SRPD,SMT
Flash write enable, active low / IO
76 IOCS#
InOut 4~16mA,
SRPD,SMT
Flash chip select, active low / IO
- 60 -
