6 SCL I/O Serial SCL input
7 TEST I/O Test port
8 VDD I Positive Power Supply
3.5.3 function introduction to CS5340
1. DESCRIPTION
The CS5340 (U203) is complete analog-to-digital converter for digital audio systems. It performs
sampling, analog-to-digital conversion and anti-alias iltering, generating 24-bit values for both left and right
inputs in serial form at sample rates up to 200 kHz per channel.
The CS5340 uses a 5th-order,multi-bit delta-sigma modulator followed by digital filtering and decimation,
which removes the need for an external anti-alias filter.
The CS5340 is ideal for audio systems requiring wide dynamic range, negligible distortion and low noise,
such as set-top boxes, DVD-karaoke players, DVD recorders, A/V receivers, and automotive applications.
2. FEATURES
Advanced multi-bit Delta-Sigma architecture
24-bit conversion.
Supports all audio sample rates including 192kHz.
101dB Dynamic Range at 5V.
-94 dB THD+N.
High pass filter to remove DC offsets.
Analog/digital core supplies from 3.3V to 5V..
Linear phase digital anti-alias filtering.
Auto-mode selection.
Pin compatible with the cs5341
3. PIN DESCRIPTION
PIN No. Symbol I/O Description
1 M0 I Mode selection 0
2 MCLK I Master clock
3 VL I Logic power
4 SDOUT O Serial audio data output
5 GND I GND
6 VD I Digital power
7 SCLK I Serial clock
