BBK DV718SI - Chapter Six BOM List

MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0090001 SMD RESISTOR 1/16W 0O±5% 0603 C717,C720,C722
0090006 SMD RESISTOR 1/16W 75O±5% 0603 R717~R719,R706
0090238 SMD RESISTOR 1/16W 68O±5% 0603 R703
0090181 SMD RESISTOR 1/16W 100O±5% 0603 R702
0090008 SMD RESISTOR 1/16W 220O±5% 0603 R701
0090017 SMD RESISTOR 1/16W 2.2K±5% 0603 R710,R714
0090019 SMD RESISTOR 1/16W 4.7K±5% 0603 R704
0700007 SMD DIODE 1N4148
D701,D702 ①
0700001 SMD DIODE LS4148
D701,D702 ①
0700002 SMD DIODE LL4148
D701,D702 ①
0780050 TRIODE S8050D V701,V702
0310326 SMD CAPACITOR 50V 121±5% NPO 0603 C701~C706
0700004
SMD VOLTAGE REGULATOR
DIODE
5.1V±5% 1/2W ZD701~ZD707
0310066 SMD CAPACITOR 50V 102±10% X7R 0603 C723,C716,C727
0310207 SMD CAPACITOR 50V 104 ±20% X7R 0603
C710,C728 ②
0310543 SMD CAPACITOR 50V 104±10% X7R 0603
C710,C728 ②
0310234 SMD CAPACITOR 16V 105 +80%-20% Y5V 0603 C711
0090029 SMD RESISTOR 1/16W 47K±5% 0603 R715
0390095 SMD MAGNETIC BEADS FCM1608K-221T05 L707,L708,L709
0700056 SMD DOUBLE DIODE MMBD4148SE SOT-23 D703~D705
0390096 SMD INDUCTOR 1.8UH±10% 1608 L701~L703
0390057 MAGNETIC BEADS INDUCTOR RH354708 L713~L715
0000273 CARBON FILM RESISTOR 1/4W33O±5% SHAPED 10 R708
0000278 CARBON FILM RESISTOR 1/4W330O±5% SHAPED 10 R709
1090045
ELECTRO-OPTIC
TRANSFORMER
TX179ATW
JK705 ③
1090024
ELECTRO-OPTIC
TRANSFORMER
TX179AT
JK705 ③
1910078 TERMINAL SOCKET AV4-8.4-6G-3 JK702
1860029 SCART SOCKET SCART-01 JK706
Chapter six BOM List
DV718SI（RU）SILVER[1389HD]
AV BOARD：(7DV718-0 DV718SI(RU) SILVER[1389HD]) 5448709 1.3/V2.0
- 106 -
