BBK DV718SI - Page 111

MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
1940026 SOCKET 3P 2.0mm XS702
1940024 SOCKET 5P 2.0mm XS703
1940075 SOCKET 15P 2.0mm XS701
2100010 LEAD F0.6 SHAPED 5mm JP705~JP709,JP711~JP716,JP719
2100003 LEAD F0.6 SHAPED 7.5mm JP701,JP704,JP710,JP717,JP718
2100004 LEAD F0.6 SHAPED 10mm JP703
2100006 LEAD F0.6 SHAPED 12.5mm JP702
1564359 PCB 7DV718-0
0090324 SMD RESISTOR 1/16W 0O±5% 0402 R213,R214,R318
0090445 SMD RESISTOR 1/16W 1O±5% 0402 R321
0090457 SMD RESISTOR 1/16W2.2O±5% 0402 R706
0090507 SMD RESISTOR 1/16W 4.7O±5% 0402 R301,R302
0090106 SMD RESISTOR 1/16W 4.7O±5% 0603 R303
0090005 SMD RESISTOR 1/16W 33O±5% 0603 R222,R265,R360~R363,R274,R275
0090330 SMD RESISTOR 1/16W 33O±5% 0402 R350,R234,R349,R235~R237,R206
0090336 SMD RESISTOR 1/16W75O±5% 0402 R224,R246~R248
0090759 SMD RESISTOR 1/16W 150O±5% 0402 R287
0090338 SMD RESISTOR 1/16W91O±5% 0402 R223
0090350 SMD RESISTOR 1/16W330O±5% 0402 R227,R337,R340,R381,R277,R2160,R2161
0090012 SMD RESISTOR 1/16W 560O±5% 0603 R207
0090356 SMD RESISTOR 1/16W560O±5% 0402 R239
0090014 SMD RESISTOR 1/16W 1K±5% 0603 R208,R220,R348,R289
0090362 SMD RESISTOR 1/16W 1K±5% 0402
R232,R233,R286,R2103,R2104,R2135~R2
146
0090377 SMD RESISTOR 1/16W 4.7K±5% 0402 R2117~R2122
0090020 SMD RESISTOR 1/16W 5.1K±5% 0603 R238,R240,R241,R242,R331
0090378 SMD RESISTOR 1/16W 5.1K±5% 0402 R326
0090023 SMD RESISTOR 1/16W 10K±5% 0603 R219,R221,R314
0090385 SMD RESISTOR 1/16W 10K±5% 0402
R201,R285,R288,R297,R309,R311,R313,R
324,R329,R330,R364,R2105~R2109,R2123
~R2128
0090387 SMD RESISTOR 1/16W 12K±5% 0402 R323
DECODE BOARD：2DV718-2 1.8/Ver2.3
DV718SI（RU）SILVER[1389HD]
- 107 -
