BBK DV718SI - Page 112

MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0090389 SMD RESISTOR 1/16W 15K±5% 0402 R202,R211
0090391 SMD RESISTOR 1/16W 20K±5% 0402 R325
0090394 SMD RESISTOR 1/16W 27K±5% 0402 R203,R204
0090395 SMD RESISTOR 1/16W 30K±5% 0402 R2113~R2116
0090034 SMD RESISTOR 1/16W 100K±5% 0603 R210
0090398 SMD RESISTOR 1/16W 39K±5% 0402 R2111,R2112
0090408 SMD RESISTOR 1/16W 100K±5% 0402
R215,R281~R284,R308,R310,R2101,R214
7~R2152
0090001 SMD RESISTOR 1/16W 0O±5% 0603 R295
0090412 SMD RESISTOR 1/16W 150K±5% 0402 R319,R320
0090429 SMD RESISTOR 1/16W 680K±5% 0402 R317,R322
0100019 SMD RESISTOR NETWORKS 1/16W 33O±5% 8P RN201,RN202
0090668 PRECISION SMD RESISTOR 1/16W 750K±1% 0402 R209
0310415 SMD CAPACITOR 50V 20P±5% NPO 0402 C223
0310190 SMD CAPACITOR 50V 27P±5% NPO 0603 C275,C276
0310424 SMD CAPACITOR 50V 47P±5% NPO 0402 C257~C259
0310432 SMD CAPACITOR 50V 101±5% NPO 0402 C255,C256,C2111~C2116,C283~C288
0310392 SMD CAPACITOR 50V 102±10% X7R 0402
C224,C309,C2135,C2117~C2122,C705,C7
06
0310726 SMD CAPACITOR 16V 104±10% X5R 0402
C207~C209,C211,C214,C225,C227~C229,
C253,C254,C264,C265,C279,C281,C301,C
313,C314,C316,C338,C345,C346,C2131,C
2149,C2158,C2137~C2142,C2145~C2148,
C2152
0310207 SMD CAPACITOR 50V 104 ±20% X7R 0603
C216,C218,C230~C236,C244~C252,C272,
C302~C306,C262,C263,C2150,C2151,C27
4,C339,C2143,C2144,C333,C334,C217
0310234 SMD CAPACITOR 16V 105 +80%-20% Y5V 0603
C201~C205,C239,C240,C317~C322,C2130
,C2132,C2133,C2134
0310201 SMD CAPACITOR 50V 153±10% X7R 0603 C238,C268
0310394 SMD CAPACITOR 50V 222±10% X7R 0402 C307,C308
0310068 SMD CAPACITOR 50V 222±10% X7R 0603 C237
0310454 SMD CAPACITOR 16V 153±10% X7R 0402 C210,C310,C311
0310794 SMD CAPACITOR 16V 331±5% NPO 0402 C212,C213
0310570 SMD CAPACITOR 16V 333 ±10% X7R 0402 C226
0310795 SMD CAPACITOR 16V 391±5% NPO 0402 C219
0310482 SMD CAPACITOR 16V 473 ±10% X7R 0402 C221,C222
- 108 -
