BBK DV718SI - Page 113

MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0310362 SMD CAPACITOR 16V474 +80%-20% Y5V 0603 C220
0390453 SMD MAGNETIC BEADS GZ1005D221T 0402 R264,L205,L207
0390095 SMD MAGNETIC BEADS FCM1608K-221T05
L202,L206,L208,L209,L218~L224,L307,L30
8,L311,L316
0390444 SMD MAGNETIC BEADS PZ2012U121 L210,L211,L235,L315
0390452 SMD MAGNETIC BEADS PZ3216D121 L212
0390096 SMD INDUCTOR 1.8UH±10% 1608 L225~L227
06801009 SCHOTTKY DIODE SR260 DO-15 BELT D301
0390274 SMD INDUCTOR 1.2UH±10% 1608 R205
0390355 SMD INDUCTOR 4.7UH±10% 1608 L203,L309,L312
0390385 SMD INDUCTOR 22uH±10% 2012 L204
0700056 SMD DOUBLE DIODE MMBD4148SE SOT-23 D209~D211
0700004
SMD VOLTAGE REGULATOR
DIODE
5.1V±5% 1/2W D205~D208,D218,ZD201~ZD203
0700113
SMD VOLTAGE REGULATOR
DIODE
9.1V±5% 1/2W D217
0780062 SMD TRIODE 9014C Q220
0780115 SMD TRIODE 2SB1132 Q301,Q302
0780193 SMD TRIODE 2SK3018 Q303,Q304
0780040 SMD TRIODE 3904(100-300) SOT-23 Q305
0780198 SMD TRIODE 2SA1015 Q211,Q213,Q214
0780197 SMD TRIODE C1815 Q201,Q205~Q210,Q212
0700007 SMD DIODE 1N4148 D201,D203,D204,D215,D216
02607829 CD CD11C 10V220U±20%6×12 C5 BELT TC301
02600279 CD CD11 16V100U±20%6×12 2.5 BELT TC222,TC223
02607819 CD CD11C 10V100U±20%5×11 C2.5 BELT
TC203,TC207,TC218,TC308,TC309,TC235,
TC238
02602229 CD CD11C 10V220U±20%6×7 2.5 BELT TC204,TC209,TC304,TC305
02607809 CD CD11C 10V47U±20%4×7 C2.5 BELT TC208,TC219,TC302,TC303
02607799 CD CD11C 16V10U±20%4×7 C2.5 BELT
TC201,TC202,TC205,TC206,TC215,TC240
~TC252
0880322 IC MM74HCU04M SOP
U205 ④
0880513 IC HCU04 SOP
U205 ④
0882353 IC CS5340 TSSOP U203
08828028 IC AM5888S L/F HSOP$ U302
0882644 IC MT1389FE/H(HD) QFP U201
- 109 -
