MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0881415 IC HY57V641620HGT-7 TSOP U208
0881742 IC F4558 SOP U209,U210,U211
0881947 IC A21SC SOP U202
0960020
CMETAL OXIDE FILM
RESISTORSTAL OSCILLATOR
27.00MHz 49-S X201
07803199 TRIODE SS8550 TO-92 BELT Q306,Q307,Q308,Q309
05700039 DIODE 1N4001 BELT D302
1940022 SOCKET 4P 2.0mm XS203
1940024 SOCKET 5P 2.0mm XS306,XS208
1940005 SOCKET 6P 2.0mm XS307
1940023 SOCKET 7P 2.0mm XS201
1940008 SOCKET 8P2.0mm XS206
1940075 SOCKET 15P 2.0mm XS204
1940094 CABLE SOCKET
24P 0.5mm SMD SUBMIT MEET WITH
CLASP
XS301
1940289 CABLE SOCKET
45P 0.5mm SMD VERTICAL REVERSE
MEET WITH CLASP
XS207
1910129 TERMINAL SOCKET
SA-001-012 BLACK IRON
PIECE,SCREEN-SHIELDED
JK703
1910079 TERMINAL SOCKET AV8-8.4-6G-3 JK701
1633428 PCB 2DV718-2
0090001 SMD RESISTOR 1/16W 0O±5% 0603 R726
0090005 SMD RESISTOR 1/16W 33O±5% 0603 R757
0090009 SMD RESISTOR 1/16W 330O±5% 0603 R742
0090023 SMD RESISTOR 1/16W 10K±5% 0603 R756
0090220 SMD RESISTOR 1/16W 51O±5% 0603 R718
0090014 SMD RESISTOR 1/16W 1K±5% 0603 R730,R731
0090249 SMD RESISTOR 1/16W 510O±5% 0603 R723
0090012 SMD RESISTOR 1/16W 560O±5% 0603 R724
0310199 SMD CAPACITOR 50V 562±10% X7R 0603 C747
0310066 SMD CAPACITOR 50V 102±10% X7R 0603 C752
0310207 SMD CAPACITOR 50V 104 ±20% X7R 0603
C740,C742~C746,C749,C750,C751,C736~
C739 ⑤
0310543 SMD CAPACITOR 50V 104±10% X7R 0603
C740,C742~C746,C749,C750,C751,C736~
C739 ⑤
DV718SI（RU）SILVER[1389HD]
HIGH DEFINITION SCREEN 5448708
