MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0390095 SMD MAGNETIC BEADS FCM1608K-221T05 L715~L719,L721,L724
0260028 CD CD11 16V220U±20%6×12 2.5 TC701,TC702
0090181 SMD RESISTOR 1/16W 100O±5% 0603 R701,R702
0882969 IC MT1392 QFP(C EDITION) U701
1860102 HDMI 51U019S-333N-A JK708
1940289 CABLE SOCKET
45P 0.5mm SMD VERTICAL REVERSE
MEET WITH CLASP
XS703
1940024 SOCKET 5P 2.0mm XS701,XS704
1633343 PCB TDV985-1
3072182 LAMP BRACKET DV985
0620002 RADIATION DIODE F3 RED VD406
1200788 LEDDISPLAY SCREEN 4MB40205B18 LED401
2360019 IR SENSOR AT138B U402
5230389 SOFT SPONGE SPACER
30×4.8×8 20×6×4.5 SINGLE-
FACED,HARD
0260201 CD CD11C 16V100U±20%6×7 2.5 TC401,TC402
0881687 IC SN1692 SOP U401
1340003
LIGHT TOUCH RESTORE
SWITCH
HORIZONTAL 6×6×1 K402,K403,K405
0620203 RADIATION DIODE
2B 43PC COLORLESS ISSUE BLUE 2×4×
4
VD404,VD402,VD403
5235043 SOFT SPONGE SPACER 8×6×11 DOUBLE-FACED,HARD
2122382 FLAT CABLE
7P130 2.0 2 PIN,WITH NEEDLE
REVERSE 30# CORD
XS401
2122383 FLAT CABLE
4P210 2.0 2 PIN,WITH NEEDLE
TOGETHER DIRECTION 30# CORD
XS402
3072183 LIGHT CAP DV985 TRANSPARENCE
0390095 SMD MAGNETIC BEADS FCM1608K-221T05 L401
0780085 SMD TRIODE 8050D Q402,Q404
0700007 SMD DIODE 1N4148 D401~D403
0090023 SMD RESISTOR 1/16W 10K±5% 0603 R402~R404,R420
0090020 SMD RESISTOR 1/16W 5.1K±5% 0603 R410,R411,R415
0090009 SMD RESISTOR 1/16W 330O±5% 0603 R412
0090221 SMD RESISTOR 1/16W 120O±5% 0603 R407~R409
0090181 SMD RESISTOR 1/16W 100O±5% 0603 R405
DV718SI（RU）SILVER[1389HD]
MAIN PANEL 5448083
- 111 -
