BBK DV718SI - Page 116

MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0090192 SMD RESISTOR 1/16W 51K±5% 0603 R401
0310057 SMD CAPACITOR 16V 104±10% 0603 C401~C403
0310066 SMD CAPACITOR 50V 102±10% X7R 0603 C408
0700004
SMD VOLTAGE REGULATOR
DIODE
5.1V±5% 1/2W D414
1633102 PCB 4DV985-1
0090009 SMD RESISTOR 1/16W 330O±5% 0603 R601
0090012 SMD RESISTOR 1/16W 560O±5% 0603 R604
0090014 SMD RESISTOR 1/16W 1K±5% 0603 R608,R625,R626
0090001 SMD RESISTOR 1/16W 0O±5% 0603 R624,R641
0090018 SMD RESISTOR 1/16W 3.3K±5% 0603 R630
0090028 SMD RESISTOR 1/16W 33K±5% 0603 R639,R640
0090224 SMD RESISTOR 1/16W 3.9K±5% 0603 R631, R632
0090184 SMD RESISTOR 1/16W 4.3K±5% 0603 R633, R634
0090020 SMD RESISTOR 1/16W 5.1K±5% 0603 R602, R613, R623
0090023 SMD RESISTOR 1/16W 10K±5% 0603 R606,R610,R635,R636
0090026 SMD RESISTOR 1/16W 22K±5% 0603 R603
0090030 SMD RESISTOR 1/16W 56K±5% 0603 R627,R628
0090034 SMD RESISTOR 1/16W 100K±5% 0603 R617
0310047 SMD CAPACITOR 50V 101±5% NPO 0603 C606, C607, C616, C617
0260781 CD CD11C 10V100U±20%5×11 C2.5 TC607
0310066 SMD CAPACITOR 50V 102±10% X7R 0603 C608
0310072 SMD CAPACITOR 50V 103±10% X7R 0603 C603
0310207 SMD CAPACITOR 50V 104 ±20% X7R 0603
C601,C602,C604,C605,C623,C626,C627
⑥
0310222 SMD CAPACITOR 25V 104±20% X7R 0603
C601,C602,C604,C605,C623,C626,C627
⑥
0310543 SMD CAPACITOR 50V 104±10% X7R 0603
C601,C602,C604,C605,C623,C626,C627
⑥
0310234 SMD CAPACITOR 16V 105 +80%-20% Y5V 0603 C609,C611,C612
0000118 CARBON FILM RESISTOR 1/6W10O±5% SHAPED 7.5 R621,R622
03900579 MAGNETIC BEADS INDUCTOR RH354708 BELT L605
0000339 CARBON FILM RESISTOR 1/6W3.3K±5% SHAPED 7.5 R629
DV718SI（RU）SILVER[1389HD]
OK BOARD 5448710
