MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0000134 CARBON FILM RESISTOR 1/6W5.1K±5% SHAPED 7.5 R611
0260094 CD CD110 16V47U±20%5×11 2
TC614~TC618 ⑦
0260025 CD CD11 16V47U±20%5×11 2
TC614~TC618 ⑦
0260200 CD CD11C 16V47U±20%5×7 2
TC614~TC618 ⑦
0260327 CD GZ16V100U±20%6×12 2.5
TC619, TC620 ⑧
0260027 CD CD11 16V100U±20%6×12 2.5
TC619, TC620 ⑧
0260096 CD CD110 16V100U±20%6×12 2.5
TC619, TC620 ⑧
0260175 CD CD11C 16V100U+20%-15%6×7 2.5
TC619, TC620 ⑧
0260201 CD CD11C 16V100U±20%6×7 2.5
TC619, TC620 ⑧
0260021 CD CD11 16V22U±20%5×11 2
TC605 ⑨
0260037 CD CD11 25V22U±20%5×11 2
TC605 ⑨
0390095 SMD MAGNETIC BEADS FCM1608K-221T05 L601
0260237 CD CD11 10V1000U±20%8×14 3.5
TC601 ⑩
0260352 CD GS 10V1000U±20%8×14 3.5
TC601 ⑩
0700020
SMD VOLTAGE REGULATOR
DIODE
6.2V±5% 1/2W ZD601
0780085 SMD TRIODE 8050D Q601,Q602
0880124 IC NJM4558D DIP
U601 ⑾
0880308 IC KA4558 DIP
U601 ⑾
0881537 IC TDA1308 SOP U603
1980018 MICROPHONE SOCKET CK3-6.35-24 MIC601
2122389 FLAT CABLE
8P250 2.0 2 PIN,WITH NEEDLE
REVERSE 30# CORD
XS601
2150296 FLAT CABLE
3P180 2.0 T2 1 SHIELD,WITH NEEDLE
REVERSE 28# CORD
XS603
1564414 PCB 6DV718-1
2100010 LEAD F0.6 SHAPED 5mm JP604,JP607,JP608,JP609,JP610
2100003 LEAD F0.6 SHAPED 7.5mm JP601,JP602,JP605,JP603
1860047 USB SOCKET CAM-B85-4Pin JK602
2100004 LEAD F0.6 SHAPED 10mm JP606
1980046 EARPHONE SOCKET ST-301-030-100 JK601
3870115
GROUND CHIP OF POWER
BOARD
AB903 G601, G602
DV718SI（RU）SILVER[1389HD]
POWER BOARD 5448711
