MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
3870115
GROUND CHIP OF POWER
BOARD
AB903 G501~G504
2300049 FUSE @T1.6AL 250V 3.6×10 VDE F501
1940045 SOCKET 2P 8.0mm 2# BCN501
1940022 SOCKET 4P 2.0mm CN501
0460623
SWITCH POWER
TRANSFORMER
@BCK-19-0348 SJ T501
1000043 POWER GRID FILTER @UT-20 40mH±20%10×13 UL L501
1080032 PHOTOELECTRIC COUPLER @HS817 VDE U502
0880863 IC HA17431VP TO-92 U503
0881933 IC VIPER22A DIP8 U501
05700059 DIODE 1N4007 BELT D501~D504
0680046 SCHOTTKY DIODE SR560 DO-27 SHAPED R 17.5×8 D510
02003809 PORCELAIN CAPACITOR 100V 152±10%5MM BELT C512
05700149 DIODE HER107 BELT D505,D508,D511
05700139 DIODE HER105 BELT D506
0410011 CHOKE COIL VERTICAL 10UH 2A 5mm L507
0260341 CD ZT 400V22µ±20%f16×20 7.5 TC501
02606879 CD CD11T 10V1000u±20%8×16 C5 BELT TC505,TC506
02607989 CD CD11T 16V470U±20%8×12 C5 BELT TC509,TC503
02606849 CD CD11T 50V47u±20%6×12 C5 BELT TC502
02002249 PORCELAIN CAPACITOR 1000V 103 +80%-20% 7.5mm BLET C502
0200359 CERAMIC CAPACITOR @250V 221±10% 10mm VDE BC503,BC504
02001389 PORCELAIN CAPACITOR 50V 104±20% 5mm BELT C505,C510,C515
02001369 PORCELAIN CAPACITOR 50V 473±20% 5mm BELT C506
0010159
METAL OXIDE FILM
RESISTOR
2W39K±5%SHAPED FLAT 15×7 R503
00100159 METAL FILM RESISTOR 1/4W10K±1% BELT R508,R509
00002159 CARBON FILM RESISTOR 1/4W9.1K±5% BELT R512
00001959 CARBON FILM RESISTOR 1/4W1K±5% BELT R507
00001859 CARBON FILM RESISTOR 1/4W330O±5% BELT R506
00001639 CARBON FILM RESISTOR 1/4W10O±5% BELT R505
2100006 LEAD F0.6 SHAPED 12.5mm JP504
2100004 LEAD F0.6 SHAPED 10mm JP505,R502
- 114 -
