b. GPIO
225 AVCM Analog AUDIO DAC reference voltage
226 AL GPIO Output
1) AUDIO DAC Left Surround channel output
2) While internal AUDIO DAC not used:
a. SDATA2
b. GPIO
227 ALS GPIO Output
1) AUDIO DAC Left Surround channel output
2) While internal AUDIO DAC not used:
a.SDATA0
b. GPIO
228 ALF GPIO Output
1) AUDIO DAC Center channel output
2) While internal AUDIO DAC not used: GPIO
229 ADACVDD1 Power 3.3V power pin for AUDIO DAC circuitry
230 ADACVDD2 Power 3.3V power pin for AUDIO DAC circuitry
Video Interface ( 18 )
196 DACVDDC Power 3.3V power pin for VIDEO DAC circuitry
195 VREF Analog Bandgap reference voltage
194 FS Analog Full scale adjustment
193 YUV0 CIN
Output
4MA, SR
1) Video data output bit 0
2) Compensation capacitor
192 DACVSSC Ground Ground pin for VIDEO DAC circuitry
191 YUV1 Y
Output
4MA, SR
1) Video data output bit 1
2) Analog Y output
190 DACVDDB Power 3.3V power pin for VIDEO DAC circuitry
189 YUV2 C
Output
4MA, SR
1) Video data output bit 2
2) Analog chroma output
188 DACVSSB Ground Ground pin for VIDEO DAC circuitry
187 YUV3 CVBS
Output
4MA, SR
1) Video data output bit 3
2) Analog composite output
186 DACVDDA Power 3.3V power pin for VIDEO DAC circuitry
185 YUV4 Y/G
Output
4MA, SR
1) Video data output bit 4
2) Green or Y
184 DACVSSA Ground Ground pin for VIDEO DAC circuitry
183 YUV 5 B/Cb/Pb
