Diagnosis - Diag Messages
EL70x1 235Version: 4.4
Text ID Type Place Text (English only) Cause
0x0001 Information System No error No error
0x0002 Information System Communication established Communication established
0x0003 Information System Initialization: 0x%X, 0x%X, 0x
%X
General information; parameters depend on event. See
device documentation for interpretation.
0x1000 Information System Information: 0x%X, 0x%X, 0x%X General information; parameters depend on event. See
device documentation for interpretation.
0x1100 Information General Detection of the mode of operation ended
0x1135 Information General Cycle time OK
0x1201 Information Communication Communication re-established Communication to the field side restored
This message appears, for example, if the voltage was
removed from the power contacts and re-applied during
operation
0x1300 Information Encoder Position set - StartInputhandler
0x1400 Information Drive Drive is calibrated
0x4000 Warning Warning: 0x%X, 0x%X, 0x%X General warning; parameters depend on event. See de-
vice documentation for interpretation.
0x4101 Warning General Terminal-Overtemperature Overtemperature. The internal temperature of the termi-
nal exceeds the parameterized warning threshold
0x4300 Warning Encoder Sub-increments deactivated (despite activated configura-
tion)
0x4301 Warning Encoder Encoder-Warning General encoder error
0x4400 Warning Drive Drive is not calibrated
0x4401 Warning Drive Start type is not supported
0x4402 Warning Drive Command rejected
0x4405 Warning Drive Modulo sub-type invalid
0x4410 Warning Drive Target position exceeded
0x4411 Warning Drive DC-Link undervoltage (Warning) The DC link voltage of the terminal is lower than the pa-
rameterized minimum voltage. Activation of the output
stage is prevented
0x4412 Warning Drive DC-Link overvoltage (Warning) The DC link voltage of the terminal is higher than the pa-
rameterized maximum voltage. Activation of the output
stage is prevented
0x4413 Warning Drive I2T-Model Amplifier overload
(Warning)
- The amplifier is being operated outside the specification
- The I2T-model of the amplifier is incorrectly parameter-
ized
0x4414 Warning Drive I2T-Model Motor overload
(Warning)
- The motor is being operated outside the parameterized
rated values
- The I2T-model of the motor is incorrectly parameterized
0x4415 Warning Drive Speed limitation active The maximum speed is limited by the parameterized ob-
jects (e.g. velocity limitation, motor speed limitation). This
warning is output if the set velocity is higher than one of
the parameterized limits
