Beckhoff EtherCAT EL6752 User Manual

Parameterization and commissioning
EL6752 77Version: 2.1
6.7.2.2.1 Objects for the parameterization
Index 8000 configuration data
Index (hex) Name Meaning Data type Flags Default
8000:0 Configuration Data Max. Subindex UINT8 RW 0x33 (51
dez
)
8000:01 MAC ID DeviceNet device address (see DeviceNet specification) UINT16 RW 0x0000 (0
dec
)
8000:03 ProductName Product name OCTET-
STRING[32]
RW {0}
8000:04 Device Type Device type (see DeviceNet specification) UINT16 RW 0x0000 (0
dec
)
8000:05 Vendor ID Manufacturer ID (see DeviceNet specification) UINT16 RW 0x0000 (0
dec
)
8000:06 Product Code Product code (see DeviceNet specification) UINT16 RW 0x0000 (0
dec
)
8000:07 Revision Number Version number (see DeviceNet specification) UINT16 RW 0x0000 (0
dec
)
8000:08 Serial Number Serial number (see DeviceNet specification) UINT32 RW 0x00000000
(0
dec
)
8000:1D Network Flags Reserved for AMS via DeviceNet UINT16 RW 0x0000 (0
dec
)
8000:1E Network Port Reserved for AMS via DeviceNet UINT16 RW 0x0000 (0
dec
)
8000:1F Network Segment Ad-
dress
Reserved for AMS via DeviceNet OCTET-
STRING[2]
RW {0}
8000:20 Allocation Choice DeviceNet mode selection (see DeviceNet specification)
Bit 0: reserved (0)
Bit 1: Polled
Bit 2: Bit-Strobed
Bit 3: reserved (0)
Bit 4: Change of State
Bit 5: Cyclic
Bit 6: Acknowledge Suppression
Bit 7: reserved(0)
UINT16 RW 0x0100
(256
dec
)
8000:21 Expected Packet Rate
- Poll
Timing parameter for the poll connection (see DeviceNet
specification)
UINT16 RW 0x0000 (0
dec
)
8000:22 Expected Packet Rate
- Bit Strobe
Timing parameter for the bit strobe connection (see De-
viceNet specification)
UINT16 RW 0x0000 (0
dec
)
8000:23 Expected Packet Rate
- COS/Cyclic
Timing parameter for the COS/cyclic connection (see De-
viceNet specification)
UINT16 RW 0x0000 (0
dec
)
8000:24 Produced Data Size -
Poll
Data length in poll mode UINT16 RW 0x0000 (0
dec
)
8000:25 Produced Data Size -
Bit Strobe
Data length in bit strobe mode UINT16 RW 0x0000 (0
dec
)
8000:26 Produced Data Size -
COS/Cyclic
Data length in change of state / cyclic mode UINT16 RW 0x0000 (0
dec
)
8000:27 Consumed Data Size
- Poll
Data length in poll mode UINT16 RW 0x0000 (0
dec
)
8000:28 Consumed data size -
Bit strobe
Data length in bit strobe mode UINT16 RW 0x0000 (0
dec
)
8000:29 Consumed Data Size
- COS/Cyclic
Data length in change of state / cyclic mode UINT16 RW 0x0000 (0
dec
)
